When you want to create a safe platform/working deck in a lift shaft you should use Platform consoles that are fastened to the inside of the shaft wall. When the platform consoles have been installed, grade timber of correct dimensions should be used to create the platform level.
• Bracket that creates flats at openings and shafts.
• Installed with console tenon.
• Maximum load 1,000 kg/console.
• Weight 1,4 kg.
Art. No. 930089
Compression post is used as for installing edge protection between concrete slabs and other situations at construction sites. Utilizing the Compression post together with Barrier and Containment net a fully covered opening can be achieved. The containment net stops debris and material from entering or exiting the floor and the Barrier acts as collective fall protection. The Compression post is easy to install by extending the inner pipe to the ceiling and then activating the compression function by a foot pedal.
• Tool free installation.
• Adjustable length 2,2-3,5 m (7’2”-11’5”).
• Tension load (FT) 100-150 kg.
• Fits with various barrier brackets.
• Hot dip galvanized.
• Weight 10,5 kg.
• EN 13374 A, OSHA 1926.502 (B).
• Delivered 50 pcs in stackable pallet.
Art.no. 913151
We update ourselves continuously to always be at the forefront. We have recently had training for our staff in the latest about our products and regulations in personal fall protection. We have trained in rescue, inspection of equipment, service and repairs among other things. Training was held in our premises at the SafetyRespect Academy in Stockholm with an instructor from www.savealife.at
Read more about SafetyRespect Academy here https://www.safetyrespect.se/academy
Published September 15, 2022.
When working on facades and roofs Flex working platform can be installed to create a safe working area. The system is both faster to install and more flexible than traditional scaffolds. The system can be adapted to most situations. Installation is mainly done by SafetyRespect in consultation with the customer.
The working platform has a type approval certificate as a scaffold issued by SP (Technical Research Institute of Sweden) in load class 2 and 3 according to AFS 1990:12.
• Flexible installation on wall, floor structure or truss.
• Used with boardwalk steel sheet.
• Configured according to requirement.
• Hot galvanized components.
• Load classification 2 and 3.
• Console weight from 12 kg.
Art. No. 981122
At roof eaves, Flex eave bracket can be installed as an attachment for edge protection. This solution enables a free working space and the distance between the facade and edge protection can be adjusted during ongoing work. The bracket is installed with a through bolt in the roof frame and supports even against the facade or the roof frame.
• Adjustable bracket.
• Configured according to requirement.
• Robust and durable.
• Galvanised components.
• Weight from 5,1 kg.
Art. No. 914123
At roof gables the Flex gable bracket can be installed as an attachment for temporary safety barriers, which creates a free working area. The distance between the facade and the edge protection can be adjusted during ongoing work. The attachment can be done in the roof base.
• Adjustable bracket.
• Configured according to requirement.
• Robust and durable.
• Galvanised components.
• Weight from 5,1 kg.
Art. No. 914124
At roof eaves Flex eave brackets with counterhold can be installed as an attachment for temporary edge protection. The attachment makes possible a free working space and the distance between the facade and edge protection can be adjusted during ongoing work. The bracket is installed with through bolt in the roof frame and supports even against the facade or the roof frame.
• Adjustable bracket.
• Configured according to requirement.
• Robust and durable.
• Galvanised components.
• Weight from 5,1 kg.
Art. No. 914125
Post 1,5 m alu is used for installing barriers as collective edge protection on construction sites. Made of aluminum pipe 48,3 x 4,0 mm with integrated post lock.
• Weight 3,2 kg.
• 100 pieces delivered in stacking stillage.
Art.no. 911116
Slab edges are present everywhere on construction sites and are an usual cause of fall accidents. Socket base can be installed as attachment for edge protection on the slab edge, stairs and other situations where there is a risk of falling. Our solution can be installed on all types of material and they are very fast and flexible as, for example, when walls are to be installed. When the safety barrier is in its lowest position it seals against the slab, and it can easily be raised on the post for various kinds of work at the slab edge.
• Integrated post lock.
• Several bolt alternatives.
• Hot dip galvanized.
• Weight 1,0 kg.
• 150 pieces delivered in stacking box stillage.
Art. No. 912110
When steel beams are used in the building construction a Welding socket with integrated post lock should be designed as an attachment of edge protection. In these cases the Welding socket is welded according to the instructions when producing the steel beams. When the beam has been lifted in place Post 1,3 m and Barrier 2,6 are mounted. The attachment of the edge protection will become both safer and faster with a pre-fabricated attachment such as this one.
• For welding on steel structures.
• Available with and without bottom.
• Integrated post lock.
• Untreated.
• Standard height 150 mm.
Art. No. 914009
